The drone boasts a dead cat design that enhances stability, extends battery life and provides an unobstructed flying experience with hidden propellers.
Flywoo BNF Firefly DC16 Nano Baby Analog V2.0 1.6" 1S Deadcat Micro Quad Drone with ELRS 2.4GHz Receiver - Perfect for FPV Racing and Indoor Flying
$112.19
$203.99
Safe 45%
Flywoo BNF Firefly DC16 Nano Baby Analog V2.0 1.6" 1S Deadcat Micro Quad Drone with ELRS 2.4GHz Receiver - Perfect for FPV Racing and Indoor Flying
$112.19
$203.99
45% Off
Delivery & Return: Free shipping on all orders over $50
Estimated Delivery: 10-15 days international
21 people viewing this product right now!
SKU: 47154192
Guranteed safe checkout
Description
Features
Specifications
Experience superior performance with the Flywoo BNF Firefly DC16 Nano Baby V2.0 1S Deadcat Analog Micro Quad. Boasting a 30% power increase compared to its predecessor, it offers extended flight time while providing an incredibly stable flight experience. It comes with a new and improved canopy design for increased camera protection and a crash-resistant bottom plate for added durability. Enjoy the unmatched experience of this incredibly crafted drone from Flywoo.
Check out our other , as well as other great products from !
Features
- Redesigned canopy with enhanced aesthetics and reinforced camera protection.
- The bottom plate is thicker and has extended motor protection corners, resulting in a more stable and durable quadcopter.
- Equipped with ROBO 1002 19800Kv motor and 1608 3-bladed 40mm propellers, delivering a 30% increase in power, reduced noise, and enhanced flight stability.
- Ultra-light GOKU Versatile F411 1S VTX AIO V2 with upgraded circuit board stability and a 250mw video transmitter, enabling an extended flight range.
- A30 plug supports a continuous current of 15A, providing greater power and longer flight times compared to the PH2.0 connector.
- Upgraded Flywoo 1S Nano camera V3 delivers clearer and better image quality.
- New battery compartment design allows for easy replacement of batteries of different models.
Dead Cat Style
New Design
Redesigned canopy with enhanced aesthetics and reinforced camera protection.
Bottom plate is thicker and has extended motor protection corners, resulting in a more stable and durable quadcopter.
Bottom plate is thicker and has extended motor protection corners, resulting in a more stable and durable quadcopter.
Efficient Power Combo
Equipped with ROBO 1002 19800KV motor and 1608 3-bladed 40mm propellers, delivering a 30% increase in power, reduced noise, and enhanced flight stability.
Ultra-light AIO with 250mw VTX
The drone's GOKU Versatile F411 VTX 1S AIO V2 includes a built-in 250mW video transmitter, enabling an extended flight range and ultimate lightweight design without sacrificing performance, with improved circuit board stability.
Flywoo Nano Camera V3.0
Boasts a 4:3 aspect ratio, switchable NTSC and PAL formats, a 1/3" CMOS sensor, and global WDR, among other impressive specifications that render it an ideal choice for flying compact builds.
More Power, More Flight Time
The A30 plug can sustain a continuous current of 15A, whereas the PH2.0 connector can only support 4.5A. Given the same capacity, the A30 plug can release more current, providing greater power and, as a result, longer flight times even when flying at full speed.
Specifications
- Frame Kit: Firefly 1S DC16 Nano baby quad Frame kit
- Motor: ROBO 1002 19800KV
- Electronic: GOKU Versatile F411 VTX 1S 5A AIO V2.0 w/ 250mw vtx
- Propeller: 1608-3 Blade 40mm 1.5mm Shaft
- Camera: Flywoo 1S Nano Camera V3
- Weight: 26g
GOKU Versatile F411 VTX 1S 5A AIO V2.0 w/ 250mw VTX
Flight Controller
- MCU: STM32F411CEU6
- GYRO: ICM42688
- UARTS: 1/2
- Soft serial port1
- I2C: SCL/SDA
- BEC: 5V
- Input Voltage: 1S (<4.35v)
- Firmware: FLYWOOF411_5IN1_AIO
- Mounting: 25x25mm, M2
Onboard 4in1 ESC
- MCU: EFM8BB21
- Power supply: 1S LiPo/LiPo HVCurrent: 5A
- Firmware: BLHeli_S
- Factory firmware: O_H_5_REV16_8.HEX
- Default protocol: DSHOT 150/300/600
Onboard 5.8g VTX
- Output power: 25mw~250mw switchable
- Frequency: 40CH
- Frequency: 5.8GHz 5 bands 40 channels(include Race band) IRC ready
ROBO 1002 19800KV
- Configuration: 9N12P
- Stator Diamter: 10mm
- Stator Length: 2mm
- Shaft Diameter: 1.5mm
- Motor Dimension(Dia.xLen): Φ13.5x7.75mm
- Weight(g): 2.5(5cm wire)
- Idle current(5)@5V(A): 1.3
- No.of Cells(Lipo): 1S
- Max Continuous Power(W)3S: 44
- Internal Resistance: 89mΩ
- Max Current(3S): 11.8A
- Max Efficiency Current: (2-4A)>84%
Flywoo 1S Nano Camera V3
- Model: Flywoo 1S Nano Camera V3
- Image Sensor: 1/3" CMOS Sensor
- Horizontal Resolution: 1200 TVL
- TV System: NTSC and PAL(switchable)
- MENU: Support
- IMAGE: 4:3
- Synchronization: Internal
- Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
- S/N Ratio: >52dB (AGC OFF)
- Video Output: CVBS
- Lens: 1.8mm/F2.5
- Min. illumination: 0.001Lux
- Auto Gain Control: YES
- BLC: YES
- WDR: Global WDR
- DNR: 3D DNR
- Dimensions: 14x14mm
- Wide Power Input: DC 3.7-18V
- Work Temperature: -20°C~+60C
- Work Humidity: 20%~80%
- Weight: 2.1g
Includes
- 1x Flywoo BNF Firefly DC16 Nano Baby V2.0 1.6" 1S Deadcat Analog Micro Quad - ELRS 2.4 GHz
- 4x 1608 -3 40mm 1.5mm shaft
- 2x TPU battery mount
- 1x hardware screws set
- 4x Prop guards
